1. Input voltage : AC input signal voltage range :0.3Vp-p to 30Vp-p

                                                 DC input signal voltage range :Lo(+1V or less), Hi(+4 to 30 V)

  2. Filter : OFF / 20 kHz / 120 kHz low-pass filter

            * Signal Output Filter : OFF / 3 Hz / 10 Hz / 1 kHz selectable, low-pass filter

  3. Input impedance : 2.2 kΩ

  4. AC coupling frequency : 0.9 Hz approx. -3 dB

  5. Minimum input pulse width : 1.5 µs

  6. Input frequency range : 0.2 Hz to 320 kHz

  7. Conversion time : 1 cycle +3.5 µs or less

  8. D/A resolution : 16-bit

  9. Voltage output :

             - 0 to 10 V(Full scale mode output, direction recognition function OFF)

            - ± 5 V / ± 10 V

        Current output   :

            - 0 to 16 mA / 4 to 20 mA

                0 to 16 mA, load resistance 500 Ω or less (at the time of shipment)

10. Sensor power : +12 V±1 % 150 mA / +5 V±10 % 150 mA

11. Power requirement : 16 VCD ±10 % * Exclusive AC adapter (100 to 240 VAC)

12. 치수 : 210W×44D×200D mm(excluding protruded section) / 약 1kg

(상세 사양은 공영테크 담당자에게 문의하시거나,상기 ONO LINK를CLICK하여 참고하시기 바랍니다)
