1, 측정방식 : 접축방식

  2. 표시 : 5-digit LCD (10.5-mm character height)

  3. Measurement update time :

        1s automatic update (2s update for Lo range : 0.5 to 1.0 r/min)

        1s automatic update (2s update for Hi range : 5 to 10 r/min)

  4. Rotation speed measurement range :

          0.5 to 10,000 r/min (Lo : 0.5 to 2,000.0 r/min, Hi : 5 to 10,000 r/min)

  5. Circumferential speed measurement range :

          When the KS-200 circumferential ring (provided) is used : 0.05 to 1000.0 m/min

          When the KS-100 circumferential ring (option) is used : 0.5 to 10,000 mm/s

  6. Measurement accuracy :

          Low (Lo) range: 0.5 to 1249.9 r/min speeds Within ±0.1 r/min

                                                      1250.0 to 2000.0 r/min speeds Within ±0.2 r/min

          High (Hi) range: 5 to 10,000 r/min speeds Within ±1 r/min

  7. Memory function : 10 data can be memorized.

  8. Data hold function : Auto power off when 30 seconds have elapsed after the end of measurement.

   9. Low battery indication : The “LOW” mark is displayed when the battery voltage falls below 3.3 V.

10. Power source : Three AAA-type batteries* (1.5 V)

           Continuous measurement time: Approx. 20 hours (when alkaline batteries are used, at 20°C)

11. Operating temperature : 0 to +40°C

12. 사이즈 : 63W x 172L x 38.5D mm (약 200g)

(상세 사양은 공영테크 담당자에게 문의하시거나,상기 ONOSOKKI LINK를CLICK하여 참고하시기 바랍니다)
